Description
Specification:
Model: KW830
Support System: Engine
OBD: OBD II, EOBD
Processor: Single-chip microcomputer
Platform: Embedded System
Protocol: ISO9141, KWP2000, J1850 PWM, J1850 VPW and CAN
Output protocol: ISO9141, KWP2000, J1850 PWM, J1850 VPW and CAN
Rated operational voltage: 12V DC (Do not need batteries)
Working current: 0.042A
Operating Temperature: 0 to 60°C (32 to 140 F°)
Storage Temperature: -20 to 70°C (-4 to 158 F°)
Display: 2.8inches, 128x64 pixel display with contrast adjustment
OBDII Adaptor: 16PIN
Dimensions: 20*10*5cm
Weight: 0.66kg
Product material: ABS
Language: English, French, German, Spanish, Dutch, Russian, Italian, Portuguese.
Certification: CE, FCC, RoHS
Applicable models:
The following 12V gasoline car: Audi, Ford, Benz, BMW, Brilliance, Chevrolet, Chevy, Chrysler, Citroen, Dae woo, Daihatsu, Fiat, Ford, GM, Holden, Honda, Hyundai, Jaguar, Kia, Land Rover, Mazda, Mitsubish, Nissan, Opel, Peugeot, Porsche, Renault, Romeo, Rover, Saab, Seat, Skoda, Smart, Subaru, Suzuki, Toyota, Volvo, VW etc.
Not applicable models: Dacia, Dadi, Demo, Isuzu, Lancia, Mahindra, Maruti, Tata, Yamaha, etc.
Notes:
KW830 Code Reader can only detect 12V gasoline vehicles. All diesel vehicles, 24V carts, trucks, electric vehicles and hybrid vehicles can not be detected, but it can detect car battery voltage.
Package includes:
1* KW830 Code Reader
1* User\'s Manual
1* OBD2 Cable
1* USB Cable
1* Protective Nylon Bag
